S76 Elite – B3 (SR2)
The S76 Elite is an insurance-approved security shutter. A single skin curved steel slat combines high security with cost effectiveness. Its Elite status signifies that it has been approved by the Loss Prevention Certification Board, in this case to B3/SR2 according to LPS1175. This provides high security for large openings, such as factories, warehouses and other industrial units.
Additional details
High security commercial sites & shop front applications up to 42m². The steel S76 has been tested by the Loss Prevention Certification Board to LPS1175 (7.0), and is security rated at B3/SR2. It also has Secured by Design status. Suitable for internal face-fix, or internal reveal-fix installations. CE marked to harmonised product standard BSEN 13241-1:2003.
Single Skin 76mm (3”) curved steel.
Colour: Galvanised finish as standard. Option to powder coat any RAL / BS colour or Plastisol finish (surcharges apply). View our stocked powder coating colours here and our Plastisol range here.
Visible Surface :: 76mm
Weight per m² :: 16.7kg
Maximum Width :: 7000mm
Maximum Surface :: 18m² (tubular motor) / 42m² (outboard motor)
Manufactured from 0.8mm steel sheet. End caps are fabricated from steel plate.
Colour: Galvanised finish as standard. Option to powder coat any RAL / BS colour (surcharge applies).
Tubular Motor:
| Guide Height (mm) | Plate Size (mm) |
|---|---|
| 2250 | 355 |
| 3000 | 400 |
| 4000 | 450 |
| 5000 | 500 |
| 6000 | 550 |
Outboard Motor:
| Guide Height (mm) | Plate Size (mm) |
|---|---|
| 3000 | 400 |
| 4000 | 450 |
| 4000 | 450 |
| 5000 | 500 |
| 6000 | 550 |
| 6000 | 600 |
*Plate sizes shown as a guide only and may increase dependent on shutter width.
Note: External motor applications will require plate and enclosure sizes specific to each job.
Galvanised steel section bottom rail in ‘T’ shape. Guide channels are 65mm wide with wind locks. They are bolted onto angle for face fixed installations, or to 5mm wall box section for reveal fit (fixings supplied with shutter).
Colour: Galvanised finish as standard. Option to powder coat any RAL / BS colour (surcharge applies).
Electric: Tubular Motor = NRG Econom tubular motor & internal rocker or external key switch as standard (range of other motors available for a surcharge). Safety brake as appropriate to comply with legislation. Manual override facility & crank handle as required (surcharge applies). Numerous control option variants such as group, remote or mobile phone activation.
Outboard Motor = GfA Safedrive & Ranger three phase motors with TS959 push button control station as standard. Motors can be direct drive, chain drive or in-line design. Final configuration will be project specific but all motors incorporate a chain manual override facility as standard. Numerous control option variants such as timed closure, group, remote or mobile phone activation.
