p76 elite - sr1 lpcb Approved

p76 elite security shutter

APPLICATIONS

High security commercial sites & shop front applications up to 49m². The steel P76 has been tested by the Loss Prevention Certification Board to LPS1175 (7.0), and is security rated at SR1. It also has Secured by Design status. Suitable for internal face-fix, or internal reveal-fix installations. CE marked to harmonised product standard BSEN 13241-1:2003.

LOCKING MECHANISMS

The S76 incorporates a bullet locking system situated 1 meter from ground level, fixed to each guide channel on all shutters; side anchors inside guide; central ground anchor on the bottom lath on shutters over 3 meters wide.

CURTAIN SLAT

Single Skin 76mm (3'') curved steel.

Colour: Galvanised finish. Option to powder coat any RAL / BS colour or choose from a range of plastisol finishes (surcharges applies).

Visible Surface :: 76mm
Weight per m² :: 14.2kg
Maximum Width :: 7000mm
Maximum Surface :: 18m² (tubular), 49m² (outboard)

ENCLOSURE / HOUSING

Manufactured from 0.8mm steel sheet. End caps are fabricated from steel plate.

Colour: Galvanised finish. Option to powder coat any RAL / BS colour (surcharge applies).

TUBULAR MOTOR:

Guide Height (mm)       Plate Size* (mm)
            2250                          355
            3000                          400
            4000                          450
            5000                          500
            6000                          550

OUTBOARD MOTOR:

Guide Height (mm)       Plate Size* (mm)
            3000                          400
            4000                          450
            5000                          500
            6000                          550
            6000                          600

*Plate sizes shown as a guide only and may increase dependent on shutter width.

Note: External motor applications will require plate and enclosure sizes specific to each job.

GUIDE CHANNELS / BOTTOM SLAT

Galvanised steel section bottom rail in 'T' shape. Guide channels are 65mm wide with wind locks. They are bolted onto angle for face fixed installations, or to 5mm wall box section for reveal fit (fixings supplied with shutter).

Colour: Galvanised finish. Option to powder coat any RAL / BS colour (surcharge applies).

OPERATION

Electric:  Tubular Motor = NRG Econom tubular motor & internal rocker or external key switch as standard (range of other motors available for a surcharge). Safety brake as appropriate to comply with legislation. Manual override facility & crank handle as required (surcharge applies). Numerous control option variants such as group, remote or mobile phone activation.

Outboard Motor = GfA Safedrive & Ranger three phase motors with TS959 push button control station as standard. Motors can be direct drive, chain drive or in-line design. Final configuration will be project specific but all motors incorporate a chain manual override facility as standard. Numerous control option variants such as timed closure, group, remote or mobile phone activation.

P76 - Slat Profile.jpg
Aluroll Security Shutter Secured By Design Approved Product
POWDER COATING

POWDER COATING

Steelroll P76 ELITE - Sr1 lpcb approved DATA SHEET
