P77 Security Shutter
The P77 security shutter provides a medium security solution for commercial applications spanning openings up to 5m wide and 25m². The extruded aluminium 77mm profile allows the shutter to roll neatly into a box which is typically between 300mm and 360mm high.
Perforated sections within the profile afford 22% vision and allow air to flow through the shutter. The P77 profile can be combined with the E77 or V77 profiles, for lower or higher levels of transparency.
The P77 is typically electrically operated via a hard wired switch or remote control with appropriate safety features.
Additional details
Medium security commercial sites & shop-front applications, up to 5m wide and 25m². Affording 22% vision, the P77 is a very versatile retail security shutter as it can be combined with the E77 or V77 profiles, for lower or higher levels of transparency.
Single-skinned extruded aluminium.
Blind Surface : 77mm
Weight per m² : 7.5kg
Maximum Width : 6000mm
Maximum Surface : 25m²
Manufactured from roll-formed aluminium with a stove-enamelled finish. End caps are pressure-moulded aluminium alloy.
| Guide Height (mm) | Plate Size (mm) |
|---|---|
| 1650 | 250 |
| 2600 | 300 |
| 4640 | 360 |
*These sizes apply to standard shutter roll methods only. Reverse rolled curtains will require larger boxes than those shown. Plate sizes shown as a guide only and may increase dependent on shutter width.
Extruded aluminium 70mm, 90mm or 150mm deep guide channels and bottom slat with brush and rubber weather seals.
Electric: Somfy tubular motor as standard. Safety brake as appropriate to comply with legislation.
Manual override facility & crank handle as required (surcharge applies).
All motors have numerous control option variants. Rocker switch supplied as standard with options for key switch, remote, group or mobile phone activation.
Manual: Manual operation is available but not common as the shutter tends to be used to cover large openings.
