E37 ELITE - SR1 LPCB Approved

aluroll e37 extruded shutter

Applications

High security domestic and commercial sites. The E37 Elite is insurance approved, and included in the Secured by Design scheme. Tested according to LPS1175 (6.0), with a Security Rating (SR) of 1, the E37 Elite has been designed for external and internal window apertures and can be fitted to door openings with a maximum structural opening width of 3m.

Since the stability of the shutter contributes to the security rating, the shutter must only be fixed to approved substrates. It may be fitted internally or externally to: brick, block, aluminium box section, or steel box section.

Curtain Slat

Double-skinned extruded aluminium with security end-locks and, on an external fix, guide bullet locks.

Colours: White or brown. Option to powder coat any RAL / BS colour (surcharge applies).  View our stocked powder coating colours here.

Blind Surface :: 37.5mm
Weight per m² :: 8.1kg
Maximum Width :: 3000mm
Maximum Surface :: 9m²


Enclosure / Housing

The enclosure is manufactured from extruded aluminium with a powder-coated finish (roll-formed aluminium enclosure on internal fix).

End caps are pressure moulded aluminium alloy.

Colours: White or brown. Option to powder coat any RAL / BS colour (surcharge applies). View our stocked powder coating colours here.

Guide Height (mm)     Plate Size* (mm)
           1050                           150
           1535                           165
           1820                           180
           2795                          205
           3550                          250
           4700                          300

*Plate sizes shown as a guide only and may increase dependent on shutter width.

Guide Channels / Bottom Slat

Specially designed 60mm heavy duty guides and bottom slats made from extruded aluminium.

Colours: White or brown. Option to powder coat any RAL / BS colour (surcharge applies). View our stocked powder coating colours here.

Operation

Electric: Single phase tubular motor & remote external key-switch as standard. Numerous options such as group or remote control etc. Manual override facility as required.

Aluroll-e37-elite-security-shutter-slat-profile
Aluroll Security Shutter Secure By Design Approved Product
POWDER COATING

POWDER COATING

E37 ELITE - LPCB SR1 APPROVED SECURITY SHUTTER DATA SHEET

Click here to view, download or print.
